Vibrating Feeder

Shipping address: High-tech developmental zone, Zhengzhou, China
Feeding size: 300-1,050mm
Production capacity:80-1,000t/h
Application:Used for products classification in mining, building materials, transportation, energy, chemical and other industries.

Contact customer service online

Features
Technical data

Vibrating grizzly feeder produced by our company has following features:

Vibrating Feeder

1. Vibrating grizzly feeder produced by our company has small size, light weight, simple structure.

2. Vibrating grizzly feeder produced by our company has easy installation and maintenance and low operating costs.

3. Vibrating grizzly feeder produced by our company has high efficiency and large feeding capacity.

4. Vibrating grizzly feeder produced by our company has low noise, conducive to improving the working environment.

5. Vibrating grizzly feeder produced by our company has little dust pollution, running smoothly.

Model	Max. Feeding Size (mm)	Processing Capacity (t/h)	Motor Power (kw)	Obliquity of material trough (°)	Trough size (mm)
GZD-650×2300	300	80-100	2×1.1	10-20	650×2300
GZD-750×2500	350	100-130	2×1.1	10-20	750×2500
GZD-850×3000	400	120-150	2×3	10-20	850×3000
GZD-1000×3600	500	150-200	2×3.7	10-20	1000×3600
GZD-1100×3600	580	240-300	2×3.7	10-20	1100×3600
GZD-1300×3600	650	450-600	2×7.5	10-20	1300×3600
GZD-1500×3600	1050	450-1000	2×7.5	10-20	1500×3600
GZD-2000×3600	1200	550-1000	2×10	10-20	2000×3600
GZD-2500×5000	1500	650-1500	2×18	10-20	2500×5000
ZSW-380×95	500	100-280	8p 11	0-15	3800×280
ZSW-490×110	630	150-400	6p 15	0-10	4900×1100
ZSW-490×130	750	400-700	6p 22	0-10	4900×1300
ZSW-600×130	750	400-700	4p 22	0-10	6000×1300
ZSW-600×150	800	500-900	4p 30	0-10	6000×1500
ZSW-600×180	900	700-1300	4p 37	0-10	6000×1800
ZSW-600×200	1200	800-1500	4p 55	0-10	6000×2000

Note:processing Capacity May Vary With Different Materials And Feeding Sizes.
